| 材质 | 硅酸钙 |
|---|---|
| 产地 | 山东 莱州 |
| 产品类别 | 窑炉工业窑炉用保温材料 |
| 产品种类 | 保温板 |
| 等级 | A级 |
| 抗弯强度 | 0.60 |
| 使用温度 | 1000° |
| 形态 | 微孔状 |
| 形状 | 板材 |
| 应用范围 | 工业窑炉 |
| 种类 | 窑炉工业窑炉用保温材料 |
| 芯材 | 硅酸钙 |
| 导热系数（常温） | 0.035 |
| 品牌 | 保安得 |
硬硅钙石复合砖性能指标 Calcium Silicate Brick Tech. Data 电解铝行业 In Aluminium
| 项目 Item | 单位Unit | 标准 According To | MFDJ-30Q | MFDJ-40 |
| 温度等级 Temperature Limited | ℃ | — | 1000 | 1000 |
| 密度，±10 % Density | kg/m3 | GB/T 10699 | 300 | 400 |
| 抗压强度 Compress Strength | MPa | GB/T 5072 | ≥1.5 | ≥2.0 |
| 900℃×3 h线收缩 Linear Shrinkage | % | GB/T 10699 | ≤1.0 | ≤1.0 |
| 导热系数（热面温度900℃） Thermal cond.(hot surface at 900C) | W/(m·K) | YB/T 4130 | ≤0.11 | ≤0.11 |
产品描述Deion
产品是无机材料，主晶相是硬硅钙石，理化性能稳定。
The MFDJ calcium silicate boards are inorganic materials,the main crystal phase is the xonotlite ,with excellent physical and chemical properties.
产品基材是由硅质材料和钙质材料经蒸压水热合成的，均匀分布有大量微米级和纳米级孔隙，气孔率85~91 %，绝热性能优异。
The product composition is siliceous and calcareous materials,with a large number of micron and nanoscale porosity.
Total porosity 82~91%.
Exceptional heat resistance.
产品是背衬绝热功能材料，由其性能决定，不能用作炉衬的工作层。
The calcium silicate boards is back-up insulation material in all refractory constructions.Due to its capability, it can not be used as work layer of stove.
产品不含石棉和其它有毒有害成分；没有生物营养成分，不会腐烂、发霉，没有虫害和鼠害危险。
Asbestos free.
Non-toxic
Harmless
No nutrition
Rot-resistant and non-ageing
Insect free
产品特性 Features
热导系数低，绝热效果好 Low thermal conductivity, Exceptional heat resistance
热收缩率低，尺寸稳定 Low lining shrinkage,dimensional stability
体积密度低，热容量少 Low density, low heat capacity
理化性能稳定，耐久性好 Stable and excellent durability
产品应用 Applications
作为优异的绝热背衬材料，产品可广泛用于绝大部分工业领域的热工设备。
As excellent back-up insulations materials, it can be widely used in high-temperature process equipment.
有色冶金行业，适合于电解槽槽底和侧壁的绝热保温。
Calcium silicate boards are suitable for electrolyzer tank bottom and wall insulation.
水泥行业 In Cement
| 项目Item | 单位Unit | 标准 According To | MFSN-22 | MFSN-30Q | MFSN-30T | MFSN-50H | |
| 温度等级Temperature Limited | ℃ | - | 1000 | 1000 | 1000 | 1200 | |
| 密度，±10 % Density | kg/m3 | GB/T 10699 | 220 | 300 | 300 | 550 | |
| 抗折强度 Flexture Strength | MPa | ≥0.33 | ≥0.60 | ≥0.40 | ≥0.6 | ||
| 1000℃×3h线收缩Linear Shrinkage 3h at 1000C | % | GB/T 10699 | ≤2.0 | ≤2.0 | ≤2.0 | - | |
| 1100℃×3 h线收缩 Linear Shrinkage 3h at 1100C | - | - | - | ≤3.0 | |||
| 导 热 系 数 Thermal Cond. Hot surface at
| 热面700℃ | W/(m·K) | YB/T 4130 | ≤0.09 | - | - | - |
| 热面1000℃ | - | ≤0.12 | ≤0.10 | - | |||
| 热面1100℃ | - | - | - | ≤0.14 | |||
产品描述
产品是无机材料，主晶相是硬硅钙石，理化性能稳定。
The MFSN calcium silicate boards are inorganic materials,the main crystal phase is the xonotlite ,with excellent physical and chemical properties.
产品基材是由硅质材料和钙质材料经蒸压水热合成的，均匀分布有大量微米级和纳米级孔隙，气孔率79~91 %，其绝热性能优异。
The product composition is siliceous and calcareous materials,with a large number of micron and nanoscale porosity.
Total porosity 82~91%.
Exceptional heat resistance.
产品是背衬绝热功能材料，由其性能决定，不能用作炉衬的工作层。
The calcium silicate boards is back-up insulation material in all refractory constructions.Due to its capability, it can not be used as work layer of stove.
产品不含石棉和其它有毒有害成分；没有生物营养成分，不会腐烂、发霉，没有虫害和鼠害危险。
Asbestos free.
Non-toxic
Harmless
No nutrition
Rot-resistant and non-ageing
Insect free
产品特性Features
热导系数低，绝热效果好 Low thermal conductivity, Exceptional heat resistance
热收缩率低，尺寸稳定 Low lining shrinkage,dimensional stability
体积密度低，热容量少 Low density, low heat capacity
理化性能稳定，耐久性好 Stable and excellent durability
产品应用Applications
作为优异的绝热背衬材料，产品可广泛用于绝大部分工业领域的热工设备。
As excellent back-up insulations materials, it can be widely used in high-temperature process equipment.
水泥行业，适合用预热器、分解窑、篦冷机和三次风管等设备的绝热保温。
Calcium silicate boards are suitable for pre-heater, kiln, cooler and TAD, etc .
